Light Duty Pan Tilt Head with Load Capacity 8kg(17.6lb)

Dimension of ZN-SPL09U Light-Duty Pan Tilt Head

FAQs of ZN-SPL09U Light Duty Pan Tilt Head

Q: What is the maximum payload capacity of ZN-SPL09U?

A: The 8kg light duty pan tilt head (model ZN-SPL09U) supports a maximum payload of 8kg (17.6lbs), including camera, housing, and bracket weights. For optimal performance of this compact pan tilt unit, we recommend ≤6.5kg loads.

Q: Is the ZN-SPL09U light duty pan tilt head suitable for outdoor surveillance?
A: Our IP66 rated outdoor pan tilt head features aluminum alloy construction and downward-facing cable ports to withstand heavy rain and dust. Ideal for surveillance camera installations in harsh environments.
Critical tips:
• Orient cable entries downward to prevent water pooling
• Regularly inspect screws for rust (stainless steel bolts recommended

 Q: What customizations does ZN-SPL09U Light Duty Pan Tilt Head support?
A: We offer customization for:
• Pan/Tilt rotation speeds
• Horizontal rotation range and vertical tilt angle range.
• Load capacity
• Wiring harnesses and aviation connectors
• Control and rotation functions
• Partial shape, color, and connectors

Q: How can cameras control this pan/tilt head?
A: Any camera (analog or IP) with Pelco P/D-compatible RS485 interface can directly control the pan/tilt head. Simply connect via the RS485 communication port using a data cable.

Q: Can the pan/tilt operate in freezing temperatures?
A: Yes. With built-in low-temperature grease, it operates reliably from -35°C to +65°C (-31°F to 149°F).

Q: What devices can this pan/tilt head carry?
A: Designed as a universal pan tilt platform for security cameras, the ZN-SPL09U reliably carries：
• Box/IP cameras (up to 8kg total load)
• Bullet cameras + telephoto lenses
• IR illuminators + microphones
• Dual-spectrum thermal imagers

• Laser rangefinders + IR speed dome combos
