Features of ZN-SAT050Y Outdoor 50kg(110.37lb) Load Tilt Rotator & Positioner
★ Tilt unit, indoor/outdoor use
★ High-precision Worm Gear Transmission
★ Load capacity 50kg(110.37lb)
★ High-strength aluminum alloy construction
★ Tilt Speed: 0.01°~4°/S(Up to 15°/S; the higher the rotation speed, the lower the payload capacity)
★ Tilt Range: -60°~20°(Optional limited rotation, with a maximum angle range from -90° to +90°)
★ Preset accuracy:±0.1°
★ Support position feedback
★ RS485/RS422 pan control with Pelco P/D protocol
★ Protection grade IP66
| Model | ZN-SAT050Y |
| Max. Load Capacity | 50kg(110.37lb) |
| Load Type | Top load |
| Transmission Mode | Worm Gear Transmission |
| Pan Range | Tilt Range: -60°~20° |
| Pan Speed | 0.01°~4°/S |
| Presets | 200 |
| Preset Accuracy | ±0.1° |
| Repeated Accuracy | ±0.1° |
| Auto Cruise | Support, 2 |
| Auto Scan | Support, 1 |
| Position Passback | Query Response or Real-time Response Transmission |
| Auto Repositioning | It can be set to automatically return to position within a range of 1 to 60 minutes. |
| Auxiliary Switch | Optional |
| Salt-Spray | Optional |
| Protocol | Pelco D (optional Pelco P/ModBus-RTU) |
| Baud Rate | 9600bps (optional 2400/4800/115200 bps) |
| Communication Interface | RS485 (optional RS422/RS232/Network Interface/Wireless Remote) |
| Power Supply | DC24V (optional DC12V) |
| Power Consumption | ≤40W |
| Stsyic Power Consumption | ≤5W |
| Working Temperature | -25°C~+55°C |
| Working Humidity | 90% RH, non-condensing |
| Storage Temperature | -40°C~+65°C |
| Protection Level | IP66 |
| Size | 250mm×180mm×264mm（L×W×H） |
| Weight | 12kg(26.73lb) |
| Installation Method | Fixed installation, Vehicle-mounted, Hoisting |
Q: What is the maximum load capacity of the ZN-SAT050Y?
A: The ZN-SAT050Y can handle payloads up to 50kg, providing strong support for heavy-duty sensors, cameras, or other mounted equipment.
Q: What kind of equipment can the ZN-SAT050Y carry?
A: It is suitable for large long-range zoom cameras, thermal imaging modules, LiDAR, radar antennas, or other specialized devices that require stable tilt positioning.
Q: What is the vertical tilt angle range of the ZN-SAT050Y?
A: The maximum tilt range is ±90°, but in practical use the recommended safe range is from –60° downwards to +20° upwards, ensuring both stability and protection of the mounted payload.
Q: In which fields can the ZN-SAT050Y be applied?
A: It is widely used in border and coastal surveillance, forest fire monitoring, oil pipeline inspection, port and harbor security, and defense-related heavy-load positioning systems.
Q: Why choose the ZN-SAT050Y for industrial or defense projects?
A5: Its high payload capacity, precise worm gear transmission, and weather-resistant design make it a reliable choice for mission-critical applications where stable tilt control is essential.
