Installation interface is compatible with small cylindrical machines on the market
Supports 0~180° horizontal and 0~60° vertical panoramic monitoring
Supports multiple preset operations
Supports automatic functions such as standby actions and guard location
Supports function expansion and customization according to customer requirements
Support 5V power supply or USB power supply system for special customization
Protection grade IP66
| Model | ZN-BPT400 |
| Pan Range | Pan: 0~180° |
| Pan Speed | Pan: 0.1° to 15°/s |
| Tilt Range | Tilt: 0~60° |
| Tilt Speed | Tilt: 0.1° to 10°/s |
| Presets | 10 |
| Guard Location | Support |
| PT Speed Adaptation | Support |
| Patrol Scan | Support |
| Protocol | Pelco D/P |
| Baud Rate | 2400/4800/9600/38400bps |
| Communication Interface | TTL level Uart |
| General | |
| Power Supply | DC12V±5%； |
| Power Consumption | ≤3W |
| Ingress Protection | IP66 |
| Working Temperature | -30°C~+60°C (-22°F~ +140°F) |
| Working Humidity | ＜90%RH |
| Protection Level | IP66 |
| Weight | 0.1kg (0.22 lbs) |
Ziwin CCTV Cameras have a high quality. If you are interested in our products, please leave a message here, we will respond as soon as possible.
